MIL-P-83927B (USAF)
9 February 1981
Superseding
MIL-P-83927A(USAF)
8 April 1971
MILITARY SPECIFICATION
POWER SUPPLIES, GUIDED MISSILE LAUNCHERS, SINGLE
TYPES PP-2401B/A, PP-2401C/A, PP-2401D/A, PP-4285/A,
PP-4286/A, AND COMPOSITE TYPE PP-4506/A AND PS-10373C
This specification is approved for use by the AFLC Cataloging &
Standardization Office, Department of the Air Force and is available
for use by all Departments and Agencies of the Departmant of Defense.
1. SCOPE
1.1 General. This specification covens power supplies for the AIM-9
missle launcher. The power supply provides the missile with standby
power, fixing power, motor drive power and amplification of audio signal.
1.2 Classification. The power supply contains low voltage and high
voltage regulated supplies. For normal loads the low voltage supply is
rated 25.2 VDC 1.5 amperes and the high voltage supply is rated 175 VDC 200
milliamperes.
NOTE: PP-4506 with PS-1037-3C forms one (two-section) power supply.
APPLICABLE DOCUMENTS
2.
2.1 General. The following documents form a part of this specificat&m
to the extent specified herein. The issues in effect on the date of invit-
ation for bids or request for proposal shall apply unless particular issues
are specified.
SPECIFICATIONS
FEDERAL
Boxes, Wood, Cleted Plywood
PPP-B-601
Box, Wood, Nailed and Lock-Corner
PPP-B-621
Boxes, Fiberboard
PPP-B-636
Boxes, Fiberboard, Corrugated,
PPP-B-640
Triple-Wall
MILITARY
Capacitors, Fixed, Paper-Dielec-
MIL-C-25
tric, Direct Current (Hermet-
ically Sealed in Metal Cases),
General Specification for
FSC 1440
